Primary Applications:
All overhead irrigation, hand lines, solid sets or mechanically moved systems.
Features:
- Durable, heavy duty, all brass construction.
- Corrosion resistant Stainless Steel spring shaft.
Technical specifications:
- Body trajectory: 25 Degrees.
- 1/2" Male pipe connection.
- Pressure: 2.0 - 3.0 Bars.
- Flow: 0.67 - 1.25 m3/h (10.28-20.83 Lpm)
- Maximum spacing: 17 Mts.
- Weight: 205 Gms.
MAIN NOZZLE |
PRESSURE AT SPRINKLER |
CASTING RADIUS |
DISCHARGE |
Dia (mm) |
kPa |
m |
m3/hr |
LPM |
3.5 |
200 |
11.50 |
0.67 |
10.28 |
3.5 |
300 |
11.90 |
0.75 |
12.60 |
4.0* |
200 |
11.50 |
0.81 |
13.44 |
4.0* |
300 |
12.10 |
0.98 |
16.46 |
4.5* |
200 |
11.60 |
1.02 |
17.01 |
4.5* |
300 |
12.25 |
1.25 |
20.83 |
*Optional |
